LifeSmart Independent Photoelectric Smoke Fire Detection Alarm – Rapid Smoke Detection for Enhanced Safety

The LifeSmart Independent Photoelectric Smoke Fire Detection Alarm is a state-of-the-art safety device designed to provide early fire detection and reliable performance. By leveraging an advanced optical sensing principle, it quickly identifies smoke particles in the early stages of a fire, even during smoldering. Upon detection, the device activates an independent high-decibel alarm while simultaneously transmitting wireless signals to the gateway, allowing users to respond promptly by raising alarms, extinguishing fires, or evacuating safely.

Built for optimal performance, the device boasts a compact design, stable and sensitive photoelectric sensors, and compatibility with ZigBee protocol for seamless integration with smart home systems. It ensures consistent monitoring and provides long-lasting reliability with up to 3 years of battery life. With multiple certifications, including CCCF, CE, and FCC, the alarm meets stringent international safety standards, making it an ideal choice for residential, commercial, and industrial settings.

FEATURES:

• Advanced Photoelectric Sensing Technology: Detects smoke particles quickly and accurately during the initial smoldering stages of a fire.
• Dual Alert System: Independent sound alarm combined with wireless signal transmission to notify users promptly.
• High-Decibel Alarm Volume: Produces an audible alert of ≥ 85dB at a distance of 3 meters for effective warnings.
• Smart Connectivity: ZigBee protocol compatibility ensures seamless integration with smart home ecosystems.
• Extended Battery Life: Operates on a single CR123 battery with a lifespan of up to 3 years.
• Certified Reliability: Complies with CCCF, CE, and FCC standards for maximum safety and quality assurance.
• Flexible Installation Options: Can be mounted on ceilings or walls for optimal placement.

SPECIFICATIONS:

General:

• Model Number: MIR-SM100
• Operating Temperature: -10°C to 55°C
• Operating Humidity: 5% to 90% RH
• Detection Range: 5 meters / 120°

Power Supply:

• Battery: 1 CR123 (3V)
• Transmit Power: ≤ 10dBm
• Standby Current: ≤ 15uA
• Battery Life: Up to 3 years

Alarm Performance:

• Alarm Volume: ≥ 85dB (measured at 3 meters in front of the device)

Wireless Technology:

• Radio Protocol: ZigBee
• Signal Range (Open Field): 100 meters

Construction:

• Color: Ivory White
• Dimensions: Φ90 × 37.5mm
• Weight: 106g
• Material: ABS casing

Installation Options:

• Mounting Methods: Ceiling or wall mount

Applications:
The LifeSmart Smoke Fire Detection Alarm is perfect for homes, offices, commercial spaces, and industrial areas, offering peace of mind and enhanced safety with early fire detection and reliable performance.
